Ryzen 7 overclocking: Voltage to Temp statistic

Overclockers is supported by our readers. When you click a link to make a purchase, we may earn a commission. Learn More.

EGN

Registered
Joined
Mar 19, 2017
Location
Lviv, Ukraine
Ryzen 7 overclocking statistics

I want to overclock Ryzen 7 (1700) to 4Ghz, but I'm worried about Voltage and delivered temps.
So, lets try to make statistic look.
What is your overclocking frequency, what voltage keeps you system stable and what temperatures do you get?

Please fill online form to provide your overclocking information -> https://goo.gl/forms/JD23EJvcIsvuESPB3




Last edited:

RollingThunder

Destroyer of Trolls & Spammers
Joined
Jan 7, 2005
I want to overclock Ryzen 7 (1700) to 4Ghz, but I'm worried about Voltage and delivered temps.
So, lets try to make statistic look.
What is your overclocking frequency, what voltage keeps you system stable and what temperatures do you get?

Please fill online form to provide your overclocking information -> https://goo.gl/forms/JD23EJvcIsvuESPB3

EGN,

Putting a strange link in your first post really raises a red flag here. Please consider that from our end. I would also suggest changing your email submission from mandatory to optional.


Johan45

Benching Team Leader Super Moderator
Joined
Dec 19, 2012
I would aim for 3.8 to 3.9 with around 1.35-1.4v max for a 24/7 machine. I've overclocked two of these CPUs and so far both are over AMDs max voltage of 1.45v According to AMD 1.35v is the preferred 24/7 voltage, These CPUs are fairly new so it's "safety" limits are still kind of unknown

OP
EGN

EGN

Registered
Joined
Mar 19, 2017
Location
Lviv, Ukraine
Johan45
Thank you for the info!
My suggestion (based on multiple video- and 'paper'- reviews) it that 3.8Ghz is the sweet spot for Ryzen 1700, but it's not my own experience, so I am looking for other people opinions.

OP
EGN

EGN

Registered
Joined
Mar 19, 2017
Location
Lviv, Ukraine
So here we go! The first bunch of data

Ryzen 1700 4.0Ghz 1.45 70 Asus pro prime Dave
Ryzen 1700 3.7Ghz 1.35 85 B350 gaming 3 Spawn
Ryzen 1700 3.8Ghz 1.375 in BIOS 63.5 ASUS ROG Crosshair VI Hero MNMadman
Ryzen 1700 4.0Ghz 1.375 72 asus x370 prime sakul
Ryzen 1700 3.8Ghz 1.287 72 biostar x370 gt7 gg
Ryzen 1700X 3.9Ghz 1.37 83 MSI X370 Gaming Pro Carbon Lee
Ryzen 1700 3.8Ghz 1.395 78 Asus Prime X370-PRO deload
Ryzen 1700 3.9Ghz 1.3 63 Asrock fat4l1ty k4 Goober
Ryzen 1700 3.8Ghz 1.35 62 asrock x370 taichi NB
Ryzen 1700X 3.9Ghz 1.375 65 Crosshair VI TheWiredSoul
Ryzen 1800X 3.8Ghz 1.3375v 35 ASUS X370-PRO Kim


Johan45

Benching Team Leader Super Moderator
Joined
Dec 19, 2012
A lot of it will come down to the CPU and silicon lottery. There are some good ones but most average users will get 3.8-3.9 within the AMD recommended 1.35v. There are many factors as well such as Memory speed. I have found the higher/tighter the memory the more voltage you're going to need to keep it stable. Here's a shot of 3.8 with 3200 CL14 Set voltage is 1.35v in BIOS load voltage is closer to 1.3v in HWinfo

3800 3200 ram CL14 20 minutes stable.JPG

OP
EGN

EGN

Registered
Joined
Mar 19, 2017
Location
Lviv, Ukraine
I have 2 conclusions about Ryzen launching and overclocking capabilities:
1. I think AMD has been send selected Ryzen units for reviewers to make higher expectations for potential buyers. In head to head tests Ryzen 1700 from AMD, and from retail stores shows different overclocking capabilities. AMD sample is cooler, works with higher frequencies and need less voltage.
2. Many tests showed that 1700X is more like 1800X in therms of voltage to frequencies ratio. 1700 can overclock and work almost on 1800X frequencies, but the voltage in 1700 case is significant higher and it produces, naturally, much more heat.

So, for now I think 1700X gives margin of performance, but the price difference in real buying situation is very small, if not negotiable.


Johan45

Benching Team Leader Super Moderator
Joined
Dec 19, 2012
Not sure about the "AMD samples" being selected. I have gotten two such "samples" and they both overclock relatively the same. One is slightly better than the other. The 1700x I have will make 4.0 but still needs higher voltage of 1.42 1700 needs 1.48v. AMD has put them in the respective series for a reason. You could get lucky and find a 1700 that will clock higher with less voltage but maybe not, silicon lottery. All these CPUs came from AMD for review. For the slight difference I see the 1700 is a better choice for the money I think.


Johan45

Benching Team Leader Super Moderator
Joined
Dec 19, 2012
Yes I do. It also had a nice card inside with directions for info.

OP
EGN

EGN

Registered
Joined
Mar 19, 2017
Location
Lviv, Ukraine
Great! Maybe you can share some detailed info:
1. You have 1700 only, or 1700X and 1800X also?
2. Where were they produced (China or Malaysia)?
3. Which CPU has which maximum fully stable voltage to frequencies pair?
4. Can any one reach higher than 4.1Ghz ?
5. What cooling solution has been used?
6. What RAM, in what combination has been tested?
7. Do you have samples from regular retail stores (like Amazon, NewEgg etc.)? If so, do you have seen any differences in overclocking capabilities in compare to AMD reviewers kit sample?

Thanks!


Johan45

Benching Team Leader Super Moderator
Joined
Dec 19, 2012
Most of the info you want is in my review here http://www.overclockers.com/amd-ryzen-7-1700x-1700-cpu-review/
1. No 1800x
2. China
3. 1700 4.0 1.48v 1700x 4.0 1.42v
4. 1700x 4.2 on chilled loop 5.2 on LN2
5. Air for review NH-d15 ambient loop didn't make much more headroom
6. g.skill 3600 CL 17 all CPUs were able to run 3200 CL14 without issue. New BIOS and 1700x DDR4 3650 at CL14 still testing
7. All samples from OEM


MXstar189

New Member
Joined
Apr 21, 2017
im about same running 24/7 3.8ghz 1.36v have had it to 4.0ghz at 1.45 but wouldnt keep it there see if this link works http://valid.x86.fr/6rdk9e .......msi pro gaming carbon x370 .... r7 1700.... evga 850 platinum .... Corsair Vengeance LPX 16GB (2x8GB) DDR4 DRAM 3000MHz C15 @ 2661hz 1.35v .... asus strix rx480 at 1385hz stable ..... the cpu on custom loop with 360mm rad .... gpu on air --------------- i love the encoding performance as i do a fair amount of video production using adobe premier ... gaming just cause 3 --- gta V --- COD blops3 1080 @ 75hz on highest setting all so needless to say the money i spent im HAPPY so i would recommend

- - - Updated - - -


OP
EGN

EGN

Registered
Joined
Mar 19, 2017
Location
Lviv, Ukraine
Thank you for the statistics, guys

Ryzen 1700 4.0Ghz 1.45 70 Asus pro prime Dave
Ryzen 1700 3.7Ghz 1.35 85 B350 gaming 3 Spawn
Ryzen 1700 3.8Ghz 1.375 in BIOS 63.5 ASUS ROG Crosshair VI Hero MNMadman
Ryzen 1700 4.0Ghz 1.375 72 asus x370 prime sakul
Ryzen 1700 3.8Ghz 1.287 72 biostar x370 gt7 gg
Ryzen 1700X 3.9Ghz 1.37 83 MSI X370 Gaming Pro Carbon Lee
Ryzen 1700 3.8Ghz 1.395 78 Asus Prime X370-PRO deload
Ryzen 1700 3.9Ghz 1.3 63 Asrock fat4l1ty k4 Goober
Ryzen 1700 3.8Ghz 1.35 62 asrock x370 taichi NB
Ryzen 1700X 3.9Ghz 1.375 65 Crosshair VI TheWiredSoul
Ryzen 1800X 3.8Ghz 1.3375v 35 ASUS X370-PRO Kim
Ryzen 1700 4.0Ghz 1.4 65 Asus CH6 Brko
Ryzen 1700 3.9.Ghz 1.36 76 MSI Tomahawk B350 Fonz
Ryzen 1700 3.9.Ghz 1.45 80 b350m gaming pro hidden mang
Ryzen 1700 3.8Ghz +.222 70c GA-AB350m-G3 bud
Ryzen 1800X 3.9.Ghz 1.35 64 C Asus Prime B350-Plus None
Ryzen 1700 3.7Ghz 1.24 63.7 Asus PRIME X370 PRO damp
Ryzen 1700 3.8Ghz 1.337 67 Prime X370 jeff
Ryzen 1700 3.9.Ghz 1.325V 89 Msi B350 MORTAR Arctic Giggler
Ryzen 1700 3.9.Ghz 1.36 62 ch6 jck
Ryzen 1800X 4.0Ghz 1.4625 60C Asus Crosshair VI Hero Ackdoh
Ryzen 1700 3.7Ghz 1.25 70 X370 Me
Ryzen 1700 4.0Ghz 1.35 60 X370 Taichi Galvin
Ryzen 1700 3.7Ghz 1.18 62 ab350 skittles
Ryzen 1700X 3.9.Ghz 1.3685 64 Asrock x370 Fatal1ty Gaming K4 Gtru
Ryzen 1800X 3.9.Ghz 1.35 66 Rog crosshair vi hero Nino
Ryzen 1700 3.8Ghz 1.325 65 Asus Prime b350 plus Nil
Ryzen 1700 3.9.Ghz 1.3875 60c B350 tomahawk Princeali
Ryzen 1700X 3.9.Ghz 3.45 69.5 Msi B350 Arctic kmclaugh
Ryzen 1700 3.9.Ghz 1.344 60 Gigabyte AB-350 Gaming 3 Test
Ryzen 1800X 3.7Ghz 1.4 80 ASUS Crosshair VI Hero Neo
Ryzen 1700 3.7Ghz 1.1875 65° x370 Killer Sli Leojoy
Ryzen 1700 3.8Ghz 1.375 70 MSI B350m Gaming Pro anon76
Ryzen 1700 3.8Ghz 1.3 75 MSI X370 Carbon Virus
Ryzen 1700 3.7Ghz 1.25 75 MSI X370 PRO CARBON DUDE
Ryzen 1700 3.8Ghz 1.3 68 msi b350 tomahawk lelel
Ryzen 1700 4.0Ghz 1.41 75 Asus croshair VI Hero Alex
Ryzen 1700 3.8Ghz 1.35 45 asus prime x370 -
Ryzen 1700 3.9.Ghz 1.356 63 MSI PRO CARBON GAMING sp00ks
Ryzen 1700 3.7Ghz 1.18 76 asus prime x370-pro Kuvakei
Ryzen 1700 3.7Ghz 1.2 65 asrock gaming k4 nickname
Ryzen 1700 3.9.Ghz 1.4 45 Taichi Bdunnn
Ryzen 1800X 3.8Ghz 1.35 65 Prime X370 Pro Lilo
Ryzen 1700 3.7Ghz 1.21 66 Prime X370 Pro LiloatWork
Ryzen 1700 3.7Ghz 1.206 76 AsRock Killer SLI/ac EB
Ryzen 1700 3.7Ghz 1.25 72 Asrock X370 Taichi Jignic
Ryzen 1700 4.0Ghz 1.425 85 ASRock X370 Taichi Xetrill
Ryzen 1700 3.8Ghz 1.3 36 Asrock x370-k4 Eugene
Ryzen 1700X 3.7Ghz 1.296 81 gigabyte AB-350 gaming 3 LZC
Ryzen 1700 3.8Ghz 1.3875V 87 deg C ASUS Prime B350-Plus PetaByteBoy
Ryzen 1700 3.7Ghz 1.3 45 asus prime b350 plus suselinuxp
Ryzen 1700 3.9.Ghz 1.337 54c asus crosshair 6 hero darkengel
Ryzen 1700X 3.9.Ghz 1.352 42.25 X370 gaming pro carbon anaon
Ryzen 1700X 4.0Ghz 1.375 62c MSI X370 Carbon Gaming Pro DarthAlarak
Ryzen 1700 3.9.Ghz 1.35000 66 ASUS Prime X370-Pro tomuse
Ryzen 1700 3.7Ghz 1.21875 71 C Taichi X370 DrKleiber
Ryzen 1700 3.7Ghz 1.27 70 asus b350 plus asdas
Ryzen 1700 3.8Ghz 1.2 60 Asrock x370 Taichi Dan
Ryzen 1800X 4.1Ghz 1.441 58 (Corsair H110i) MSI X370 Gaming Carbon Pro EJ (Found Via Google Search)
Ryzen 1700 3.8Ghz 1.28125 48 MSI z370 Gaming Pro Carbon Jeff
Ryzen 1700X 4.0Ghz 1.325 60 ASRock Taichi X370 knjajzis
Ryzen 1700 3.7Ghz 1,25 65 MSI B350 Horse
Ryzen 1700 3.8Ghz 1.30 50c asrock taichi mrlski
Ryzen 1700 4.0Ghz 1,45 68 X370gtn Apo1983
Ryzen 1700 4.0Ghz 1.45 74 asrock x370 taichi Danielkill
Ryzen 1700 3.8Ghz 1.375 74 Asrock X370 Killer SLI/ac Corbitgun
Ryzen 1700 3.9.Ghz 1.406 80 B350 PLUS n
Ryzen 1700 3.7Ghz 1.3 80 Gigabyte Reissdorfus
Ryzen 1700X 3.8Ghz 1.2875 52 Asrock X370 Taichi whitedragon33
Ryzen 1700X 3.8Ghz @.35 65 MSI x370 Sli Plus Pe4ivko
Ryzen 1800X 4.1Ghz 1.35 58 crosshair vi hero Alas
Ryzen 1700 3.7Ghz 1.26 75 MSI Mortar Raf
Ryzen 1700 3.8Ghz 1.32 70 Asus B350 Prime dan
Ryzen 1700 3.9.Ghz 1.35 64 Asrock x370 Taichi adliew
Ryzen 1700X 4.0Ghz 1.4 85 Asus x390 pro Fgkris
Ryzen 1700 3.9.Ghz 1,375 60 B350 Maik
Ryzen 1700 4.0Ghz 1.35 62 GIGABYTE-AX370 Bloc
Ryzen 1700 3.8Ghz default 1.18 50 Asus B350 prime plus SHeeDeED
Ryzen 1700 4.0Ghz 1.4125 62 Asrock x370 tachi Chris
Ryzen 1700 3.8Ghz 2,625 70 Aours Gaming 5 blg
Ryzen 1700 3.8Ghz 1.368 73 Gigabyte B350 Gaming 3 Catiger
Ryzen 1800X 4.1Ghz 1.55 70 C6H Sia
Ryzen 1700 3.8Ghz 1.292 67 Ab350M g3 Bob
Ryzen 1700X 3.9.Ghz 1.35 85 asus b350 prime plus suselinuxp
Ryzen 1700 3.7Ghz 1.225 65 ASRock AB350 PRO danielcepa
Ryzen 1700X 3.8Ghz 1.350 70 Asrock X370 Professional Gaming Wulff73
Ryzen 1700 4.0Ghz 1.4125 62.2 MSI X370 SLI Plus Atham
Ryzen 1700 3.8Ghz 1.32 66 Aorus x370 gaming 5 Bunge
Ryzen 1700 3.8Ghz 1.32 66 Aorus x370 gaming 5 Bunge
Ryzen 1700 4.0Ghz 1.45 60 Asrock Electorn
Ryzen 1800X 4.0Ghz 1.43 80C Asus B350-Plus Jeff
Ryzen 1700 3.8Ghz 1.406 81 taichi strigif0rm3s
Ryzen 1700 3.8Ghz 1.3 Between 60 - 65 MSI Mortar B350M (don't buy this) Peter
Ryzen 1700 3.8Ghz 1.35 42 Asus Mom
Ryzen 1700 4.0Ghz 1.45 68c Asrock Gaming Pro Kokko
Ryzen 1700X 4.0Ghz 1.3875 55 MSI X370 Gaming Pro Carbon Z
Ryzen 1700 4.0Ghz 1.385 54c asus prime b350 plus rod
Ryzen 1700X 3.8Ghz 1.4 73 Biostar X370GTN Fatgiovanni
Ryzen 1700 3.8Ghz 1.35 66 Gigabyte GA-AX370-Gaming 5 dasman
Ryzen 1700X 3.8Ghz 1.34 70 asrock x370 professional wulff
Ryzen 1700X 3.9.Ghz 1.38 70 x370 Taichi Cletus
Ryzen 1700 3.7Ghz 1,24V 89C Gigabyte Ab350 Gaming 3 Hakem
